SPTO 2000 by Schwing
$0
SPTO 2000 by Schwing
Concrete Pump Details
Pump Specifications
Number of Strokes/Min
30/23
Main Oil Pump
N/A
Lube System (Hopper)
N/A
Max. Aggregate Size
2.5 IN
General Specifications
Hopper Vibrator
N/A
Tool Box
N/A
Water Tank
N/A
Seller Note
| 2.5 in | 63.5 mm | |
| Concrete Cylinder Diameter | 8 in | 200 mm |
| Concrete Cylinder Stroke Length | 63 in | 1600 mm |
| Differential Piston /Rod Diameter | 4.72 / 3.14 in | 120 / 80 mm |
| Outlet Diameter | 7 in | 180 mm |
| Concrete Valve Type | M Rock | |
| Shifting Cylinders | 2 | |
| Max. Pump Strokes Per Minute (Rod / Pison) | 30 / 23 | |
| Volume Control | 0 to Maximum | |
| Hydraulic System | Open Loop | |
| Main Hydraulic Pump | A11VLO190 | |
| Hydraulic Pressure | 4362 psi | 301 bar |
| Hydraulic Tank Capacity | 100 gal | 379 l |
| CAT Diesel Engine Power | 174 hp | 129.5 kW |
| Hopper Capacity | 21 cu ft | .6 cu m |
| Remote Control Cable | 100 ft | 30.5 m |
| *Pump specifications are for standard units. Other units are available. Specifications are subject to change without prior notice. |
