With variable displacement, single source hydraulics make the smallest, most economical of Olin’s S-Tube Stationary Pumps even more simple to operate. With all the same great features of the larger pumps, simplicity of design, high efficiency, maintenance friendliness, great value, and after sale support unequaled in the industry.

Weight Dry:………………………………….. 4590 lbs

Length:………………………………………… 162″

Width:………………………………………….. 70″

Hopper Height:…………………………….. 46″

Brakes:…………………………………………. Electric

Tires:……………………………………………. 225/75 R15

Axle:…………………………………………….. Torsion 5600 lbs

Hopper Capacity:………………………….. 8 cu ft

Fuel Tank Capacity:………………………. 23 gal

Engine:………………………………………… KD11903 48hp

Hydraulic Tank Capacity:………………. 81 gal

Main Hydraulic Pump:………………….. KPM K3VL60

Material Valve/Swing Tube:…………… S-Tube

Discharge Diameter Outlet:…………… 5″

Concrete Cylinder Stroke:…………….. 24″

Concrete Cylinder Diameter:………… 5″

Maximum Aggregate:…………………… 1″

Piston Head Pressure:…………………. 750 psi

Theoretical Output (C.Y.P.H.):……….. 30
